অটোক্যাড এর গুরুত্বপূর্ণ কমান্ড সমুহ

অটোক্যাডএর গুরুত্বপূর্ণ কমান্ড সমুহ

আসালামুআলাইকুম । কেমন আছেন সবাই । আশা করি ভাল আছেন। আলহামদুল্লিাহ  আমিও ভাল আছি।

আজ আপনাদের জন্য আমি কিছু অটোক্যাড এর কমান্ড শেয়ার করলাম নতুনদের জন্য উপকার হবে।

ব্লক সম্পর্কিত কমান্ড (BLOCKS) ঃ

ব্লক (BLOCKS)
NO.	SHORTCUT	COMMAND	COMMENT
1	ATT	ATTDEF	Opens attribute definition dialogue box
2	ATTEDIT	ATTEDIT	Edit attribute values for a specific block
3	B	BLOCK	Opens block dialogue box in order to make a block
4	BATTMAN	BATTMAN	Opens block attribute manager
5	BATTORDER	BATTORDER	Displays attribute order dialogue box
6	BC	BCLOSE	Closes the block editor
7	BCOUNT	BCOUNT	Counts the blocks in a drawing
8	BE	BEDIT	Opens the edit block definition dialogue box
9	EATTEXT	EATTEXT	Enhanced attribute extraction wizard to count blocks
10	GATTE	GATTE	Global attribute edit of multiple blocks
11	I	INSERT	Opens insert dialogue to insert a block
12	MINSERT	MINSERT	Insert block in rectangular array
13	REFEDIT	REFEDIT	Edit a block reference in place
14	REN	RENAME	Opens rename dialogue box to rename blocks, layers, etc
15	W	WBLOCK	Write a block - for use in other drawings
16	XLIST	XLIST	Lists type/block name/layer name/color/linetype of a
17			nested object in a block or an xref
18
19	COMMON COMMANDS
20
21	A	ARC	Draw an arc
22	AL	ALIGN	Align an object with another
23	AP	APPLOAD	Opens application load dialogue box
24	AR	ARRAY	Opens array dialogue box
25	AUDIT	AUDIT	Audit drawing for errors
26	AV	DSVIEWER	Opens ariel view of drawing
27	B	BLOCK	Opens block dialogue box
28	C	CIRCLE	Draw a circle
29	CO	COPY	Copy an object
30	CHA	CHAMFER	Chamfer between 2 non-parallel lines
31	COL	COLOR	Opens select color dialogue box
32	D	DIMSTYLE	Opens dimstyle manager
33	DC	ADCENTER	Opens designcenter
34	DI	DIST	Check a distance
35	DIV	DIVIDE	Inserts point node a set division
36	DO	DONUT	Draw a solid donut shape
37	DV	DVIEW	Perspective view
38	E	ERASE	Erase a selection
39	EX	EXTEND	Extend a selection
40	F	FILLET	Draw an arc between 2 intersecting lines
41	FI	FILTER	Opens filter dialogue box
42	FLATTEN	FLATTEN	Converts 3D to 2D
43	G	GROUP	Launches the group dialogue box
44	H	HATCH	Opens hatch and gradient dialogue box
45	I	INSERT	Insert a block
46	J	JOIN	Joins 2 objects to form single object
47	JPGOUT	JPGOUT	Creates a JPEG file of current drawing
48	L	LINE	Draw a line
49	LA	LAYER	Opens layer manager
50	LE	QLEADER	Draw a leader line (may need to adjust settings)
51	LI or LS	LIST	Display information about objects in a text window
52	LO	LAYOUT	Creates a new layout tab
53	LTS	LTScale	Change the linetype scale
54	M	MOVE	Move a selection
55	MA	MATCHPROPERTIES	Match properties of an object
56	O	OFFSET	Offset a selection
57	OP	OPTIONS	Launches options dialogue box
58	P	PAN	Pan in drawing
59	PE	POLYEDIT	Edit a polyline
60	PL	PLINE	Draw a polyline
61	PLOT/PRINT	PRINT	Opens plot/print dialogue box
62	PO	POINT	Point marker or node - DDPTYPE to change pointstyle
63	PR/CH/MO	PROPERTIES	Opens properties dialogue box
64	PU	PURGE	Opens purge dialogue box to remove unused elements
65	RE	REGEN	Regenerate the display
66	REC	RECTANG	Draw a rectangle
67	RO	ROTATE	Rotate a selection
68	SP	SPELL	Spell check a selection - ALL to check entire drawing
69	T	MTEXT	Insert multiline text
70	TB	TABLE	Opens insert a table dialogue box
71	TP	TOOLPALETTES	Displays toolpalette
72	TR	TRIM	Trim a selection
73	U	UNDO	Undo last command
74	UN	UNITS	Opens units dialogue box
75	V	VIEW	Opens view dialogue box
76	W	WBLOCK	Write a block
77	WHOHAS	WHOHAS	Displays who has a drawing open
78	X	EXPLODE	Explode a selection
79	XR	XREF	Opens x-reference manager
80	Z	ZOOM	Zoom in display - A=All, E=EXTENTS, W=WINDOW
81
82	CONTROL KEYS
83
84
85	CTRL+0	CLEANSCREEN	Turns user interface elements on/off
86	CTRL+1	PROPERTIES	Turns properties on/off
87	CTRL+2	ADCENTER	Turns design center on/off
88	CTRL+3	TOOLPALETTES	Turns tool palettes window on/off
89	CTRL+8	QUICKCALC	Launches calculator window
90	CTRL+A		Select all
91	CTRL+C	COPYCLIP	Copies objects to clipboard
92	CTRL+H		Turns a group on or off
93	CTRL+J		Repeats last command
94	CTRL+N	NEW	Opens create new drawing dialogue box
95	CTRL+O	OPEN	Opens the select file dialogue box
96	CTRL+P	PLOT	Opens the plot dialogue box
97	CTRL+R	CVPORT	Switches between viewports
98	CTRL+S	QSAVE	Save drawing as dialogue box
99	CTRL+SHIFT+		Save as
100	S
101	CTRL+V	PASTECLIP	Pastes data from clipboard to drawing
102	CTRL+X	CUTCLIP	Removes select object from drawing to clipboard
103	CTRL+Y	REDO	Performs the operation cancelled by UNDO
104	CTRL+Z	UNDO	Undoes the last operation
105	CTRL+TAB		Switches between open drawings
106	CTRL+PAGE		Switch up between layout tabs
107	UP
108
109	CTRL+PAGE		Switch down between layout tabs
110	DOWN
111
112	ARROW		Recall last command
113	UP/Down
114
115	DS	DRAFTING SETTING	Open the drafting setting dialogue box
116
117	FUNCTION KEYS
118
119
120	F1	HELP	Opens Autocad help
121	F2	TEXTSCR GRAPHSCR	Switches between text screen and graphic area
122	F3	OSNAP	Switches osnap on/off
123	F4	3D SNAP	Open the 3D object snap setting dialogue box
124	F5	ISOPLANE	Cycles through isoplanes
125	F6	COORDS	Turns coordinate display on/off
126	F7	GRID	Turns grid on/off
127	F8	ORTHO	Turns ortho on/off
128	F9	SNAP	Turns snap on/off
129	F10	POLAR	Turns polar on/off
130	F11	OSNAP TRACK	Turns object snap tracking on/off
131	F12	DYNMODE	Turns dynamic input on/off
132
133	TEXT
134
135	%%C	Ø	Diameter dimensioning symbol
136	%%D	°	Degrees symbol
137	%%O	OVERSCORE	Toggles overscore mode on/off
138	%%U	UNDERSCORE	Toggles underscore on/off
139	%%P	±	Plus/minus symbol
140
141	LAYER
142
143	LA	LAYER	Opens layer manager
144	LAYFRZ	LAYERFREEZE	Freeze a layer by selecting object
145	LAYISO	LAYERISOLATE	Isolates a layer by selecting object
146	LAYLCK	LAYERLOCK	Lock a layer by selecting object
147	LAYMCH	LAYERMATCH	Match properties of a layer
148	LAYMRG	LAYERMERGE	Moves objects from first layer to second and deletes first
149	LAYOFF	LAYEROFF	Switches a layer off
150	LAYON	LAYERON	Switches all layers on except frozen layers
151	LAYTHW	LAYTHW	Thaws all layers
152	LAYWALK	LAYERWALK	Walk through layers
153	LMAN	LMAN	Access Layer manager to save and restore layer states
154	LAYCUR	LAYERCURRENT	Change objects to current layer
155	LAYDEL	LAYERDELETE	Delete a layer by selecting object
